Additional information
Brand | |
---|---|
Frame | e-OmnIa FX Type alloy FS 29” 150mm, 1.5” tapered HT, seatpost diam. 31,6mm, integrated seat clamp, PM 180mm dropout thru axle 12x148mm, internal cable routing inside DT, Hanger compatible UDH |
Fork | Fox Float 36 Rhythm 29 , 160mm travel, damper grip, Sweep Adjust, Rebound, Float Evol spring, 1.5 tapered HT, thru axle 15x110mm, 44mm rake, w/SKS set stay mounting clamps |
Brake System | Shimano BR-MT520, 4 piston calipers, resin pad, w/203mm front & rear adapter, I-SPEC II compatible |
Headset | Fsa NO.55R/558 1.5 |
Crankset | Fsa Forged Alu, crank length 165 mm, ISIS BB axle, w/Shimano SM-CRE80-12 chainring 34T, w/custom chain guide 30-38T |
Sprocket | Shimano CS-M7100-12, 12sp, 10-51T |
Wheels | Velomann ST30 TCS 2.0 29”, 30mm internal width, 32 holes, Boost Formula Hub Microspline |
Tires | Kenda Hellkat 29×2.6, 60tpi EMC, DTC compound |
Stem | Velomann ST97Q rise 0°, 1.1/8”, diam. 35mm, length: 50mm |
Handlebar | Velomann rise, double butted AL7050, width 780mm, diam. 35mm, rise 20mm, backsweep 9° |
Saddle | Velomann 1285URN, manganese rail, 277x144mm |
Seat Post | Velomann dropper seatpost, diam. 31,6mm, internal remote cable routing w/remote control for 1x drivetrain120mm travel-43cm, 150m travel-48/53cm |
Rear Derailleur | Shimano XT RD-M8100-SGS Shadow+ Design 12sp, top normal, direct attachment, max 10-51T |
Shifters | SHIMANO DEORE SL-M6100-R 1X12SP |
Rotor | Shimano front:RT-64 FRONT & rear: RT-EM600 w/speed sensor magnet, diam. 203mm, Center Lock |
Front Light | INTEGRATED CUSTOM FRONT AND SIDE LIGHT MADE W/SPANNINGA |
Rear Light | Integrated custom rear and side light made w/Spanninga |
Motor | Bosch Performance Line CX Cruise w/Bosch PowerTube 625Wh w/Compact charger 4A 220V-240V, w/Purion |
Mudguard | Bianchi Integrated |
